Dimension (mm)

L810×W660×H760

L900×W650×H1460

Weight (kg)

105

190

Control

Industrial personal computer + motion control card

Software

Anda control software + windows system

Programming

Visual programming

Number of spindles

X、Y、Z

Spindle drive

Servo motor + module

Working area (mm)

X:260 ; Y:260 ; Z:100

Quantity of rubber valve

1 (standard configuration)

Max. Moving speed (mm/s)

800

Repeatability (mm)

± 0.025

Coating capacity (cc)

30

Valve nozzle

cleaning device

Vacuum cleaning

Equipment alarm

Menu + sound and light alarm

Coating inspection

Automatic detection

Power supply

220V 50/60Hz

Required air pressure (Mpa)

≥ 0.65

Safety standards

CE

Rated power (kw)

1

Standard configuration

CCD visual positioning;  Electrostatic interface;  232 scanner socket
